25BYT48-12Q is a special product of the company. The diameter of the motor is 28mm, and the stepper motor is equipped with a screw and an anti rotation mechanism. The rotor with plastic nuts converts the rotation of the motor into linear motion through the relative motion between the internal rotor and the screw. The length of the motor screw can be customized according to the customer's usage
The stepping angle of the motor is 15 degrees, and the lead spacing is 1mm. When the motor rotates one step, the lead moves 0.0417mm
Mainly used in valve control, automatic buttons, medical equipment, textile machines, printers, robots and other related fields.
Medical Equipment
Automatic Control
Precision Calibration
Precision Fluid Measurement
Precise Position Movement
| Product Name | 25BYT48-12Q linear stepper motor |
| Model | 25BYT48-12Q |
| Excitation | 2-2 |
| Rated Voltage | 12V |
| Phase | 2 |
| Step Angle | 7.5 degree |
| Resistance | 84Ω±10% |
| Current Per Phase | 0.143A |
| Holding Torque | 150g.cm |
| Inductance Per Phase | 48±20% (mH) At 1KHz(Ref) |
| After All Journey | 98mm |
| Life | 3000h MIN At 20℃ 100pps |
| Operating Temp Range | -10℃~40℃ |
| Storage Temp Range | -30℃~80℃ |
| Insulation Class | class E |
| Insulation Resistance | ＞100MΩ MIN At DC 500V |
| lead wrie | UL1061 28# |
| Weight | 42g |
| OEM & ODM Srvice | Available |
