Permanent magnet gear stepper motor low noise 12V 5-wire gear stepper motor
High precision, low vibration, low noise, excellent quality and long service life.
24BYJ48 stepper motor is mainly used for fans, heaters, electric heaters, sanitary ware. Thermostatic valve, burner, stage lighting equipment, microwave oven, lighting, Christmas gifts and other types of electrical appliances
Other areas where precise control is required can be achieved. The external wiring part can be wired in various types and lengths, or FPC FFC according to customer requirements.
The output part can be used in various ways, such as gear, pulley, V-groove, turbine screw, etc.
The product will be upgraded continuously, the appearance and color may change, please don't mind.
Our team has over 10 years of experience in the design, development and production of stepper motors, and can realize product development and auxiliary design according to the special requirements of our customers!
Customer's needs are our efforts, please feel free to contact us!
Technical Features
24byj48 12V Permagnent Magnet Stepper Motor with I Cut Shaft
Application Highlights
HVAC/R Valve Actuation Winding possibilities – Bipolar
Office Automation Printers, Copiers, Data storage Maintenance free - motor is brushless
Medical Applications Pill dispensing Analysers Cost effective - compact design, lower integration cost
Other Industries & Applications Robotics Digitally controlled - Easy to use with a micro processor
Telecommunication Antennae positioning Switching lines Open loop control - No encoders necessary
| Product Name | Geared stepper motor |
| Model | 24BYJ48 |
| Resistance | 200 mΩ ± 7%/ phase |
| Step angle | 5.625/64 |
| Max Starting Frequency | 500 pps |
| Max Response Frequency | 1000 pps |
| Pull in Torque | 58.8-147 gf.cm |
| Detent Torque | 49gf.cm |
| Operating Temperature Range | ≤40 ℃ |
| OEM & ODM SERVICE | AVAILABLE |
Type of Wire Connect
Motor input method with Pin type,FPC, PCB, Lead wire etc.
These can be customized according to customer needs.
Out shaft standard as follows,also can customerized due to the user drawings
welcome to contact customer service for more types
Round Type : DIA3mm. 4mm. 5mm
D-cut Type: DIA3-D2.5 DIA4-D3 etc
Screw Type: M3 M4 M5 Serial
Trape Type
I-cut Type: DIA3-I2 DIA4-I3
Other Type: Shaft with a hole etc
The regular models are shown in the figure, and the special sizes can be customized.
